AMD Ryzen™ 5 8500G 6 Cores, 5 GHz Max Boost, Radeon™ 740M Graphics

AMD Ryzen™ 5 8500G

• General Specifications

  NameAMD Ryzen™ 5 8500G

  FamilyRyzen

  SeriesRyzen 8000 Series

  Form FactorDesktops

  AMD PRO TechnologiesNo

  Regional AvailabilityGlobal

  Former CodenamePhoenix

  Architecture2x Zen 4 , 4x Zen 4c

  # of CPU Cores6

  Multithreading (SMT)Yes

  # of Threads12

  Max. Boost Clock Up to 5 GHz

  Max Zen4c Clock Up to 3.7 GHz

  Base Clock 3.5 GHz

  Zen4 Base Clock4.1 GHz

  Zen4c Base Clock3.3 GHz

  L2 Cache6 MB

  L3 Cache16 MB

  Default TDP65W

  AMD Configurable TDP (cTDP)45-65W

  Processor Technology for CPU CoresTSMC 4nm FinFET

  CPU Compute Die (CCD) Size137mm²

  Package Die Count1

  AMD EXPO™ Memory Overclocking TechnologyYes

  Precision Boost OverdriveYes

  Curve Optimizer Voltage OffsetsYes

  AMD Ryzen™ Master SupportYes

  CPU SocketAM5

  Supporting ChipsetsA620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850

  CPU Boost TechnologyPrecision Boost 2

  Instruction Setx86-64

  Supported ExtensionsAES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64

  Max. Operating Temperature (Tjmax)95°C

  Launch Date1/31/2024

  *OS SupportWindows 11 – 64-Bit Edition , Windows 10 – 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit

• Connectivity

  Native USB 4 (40Gbps)2

  Native USB 3.2 Gen 2 (10Gbps)2

  Native USB 2.0 (480Mbps)1

  PCI Express® VersionPCIe® 4.0

  Native PCIe® Lanes (Total/Usable)14 , 10

  NVMe SupportBoot , RAID0 , RAID1

  System Memory TypeDDR5

  Memory Channels2

  Max. Memory256 GB

  System Memory SubtypeUDIMM

  Max Memory Speed

  2x1R

  DDR5-5200

  2x2R

  DDR5-5200

  4x1R

  DDR5-3600

  4x2R

  DDR5-3600

• Graphics Capabilities

  Graphics ModelAMD Radeon™ 740M

  Graphics Core Count4

  Graphics Frequency2800 MHz

  DirectX® Version12

  DisplayPort™ Version2.1

  DisplayPort ExtensionsAdaptive-Sync , HDR Metadata , UHBR10

  DisplayPort Max Refresh Rates (SDR)7680×4320 @ 60Hz , 3840×2160 @ 240Hz , 3440×1440 @ 360Hz , 2560×1440 @ 480Hz , 1920×1080 @ 600Hz

  DisplayPort Max Refresh Rates (HDR)7680×4320 @ 60Hz , 3840×2160 @ 240Hz , 3440×1440 @ 360Hz , 2560×1440 @ 480Hz , 1920×1080 @ 600Hz

  HDMI® Version2.1

  HDCP Version Supported2.3

  USB Type-C® DisplayPort™ Alternate ModeYes

  Multi-Monitor SupportYes

  Max Displays4

  AMD FreeSync™Yes

  Wireless DisplayMiracast

  Max Video Encode Bandwidth (SDR)1080p630 8bpc H.264, 1440p373 8bpc H.264, 2160p175 8bpc H.264, 1080p630 8bpc H.265, 1440p373 8bpc H.265, 2160p175 8bpc H.265, 4320p43 8bpc H.265, 1080p864 8/10bpc AV1, 1440p513 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1

  Max Video Decode Bandwidth1080p60 8bpc MPEG2, 1080p60 8bpc VC1, 1080p786 8/10bpc VP9, 2160p196 8/10bpc VP9, 4320p49 8/10bpc VP9, 1080p1200 8bpc H.264, 2160p300 8bpc H.264, 4320p75 8bpc H.264, 1080p786 8/10bpc H.265, 2160p196 8/10bpc H.265, 4320p49 8/10bpc H.265, 1080p960 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1

  AMD SmartAccess MemoryAvailable

• AI Engine Capabilities

  AMD Ryzen™ AINot Available

• Product IDs

  Product ID Boxed100-100000931BOX

  Product ID Tray100-000001491 , 100-000000931

  Product ID MPK100-100000931MPK

• Security, Virtualization, and Manageability

  AMD Enhanced Virus Protection (NX bit)Yes
